Aluminum perforated sheet refers to a new type of building decoration material that uses high-quality aluminum plate to be processed and formed through multiple processes such as cutting, punching, bending, grinding and spraying, and then applied to indoor and outdoor curtain wall and ceiling decoration.
Punching plate has many excellent decorative characteristics, such as light weight, fire protection and environmental protection, wide color selection, various processable shapes and 100% recyclability. Punching plate has been widely used in indoor and outdoor decoration of urban buildings in China, especially in curtain wall and ceiling. It is mainly used in exterior wall decoration of airports, stations, stadiums, office buildings, commercial real estate, residential and other projects, overall decorative lines of buildings, commercial podium The position of door head, indoor ceiling and ceiling lamp has good decorative effects such as overall beauty, novel decoration and modern feeling.
- Alloy：1100, 3003, 5052, 5754；
- Thickness：0.4-6.0mm；
- Dimension：1.5m×5m
- Surface: PVDF color coating, PE color coating as request.
- Normal hole size:
|
Hole Size |
Diameter/mm |
Photos |
|
Circle hole |
2.5 |
 |
|
3 |
||
|
4 |
||
|
5 |
||
|
6 |
||
|
8 |
||
|
10 |
||
|
12 |
||
|
14 |
||
|
15 |
||
|
18 |
||
|
20 |
||
|
25 |
||
|
30 |
||
|
35 |
||
|
50 |
||
|
Square hole |
8×8 |
 |
|
10×10 |
||
|
14×14 |
||
|
20×20 |
||
|
30×30 |
||
|
50×50 |
||
|
Rectangular hole |
3×10 |
 |
|
3×25 |
||
|
5×30 |
||
|
6×85 |
||
|
Elliptical hole |
5 × 12 |
 |
|
6×15 |
||
|
4×30 |
||
|
9×25 |
||
|
4.76×25.4 |
||
|
Hexagonal hole |
6.928×8 |
 |
|
21.65×25 |
||
|
61.5×26×35.5 |
||
|
Equilateral triangle |
50 |
|
|
Isosceles triangle |
15.4×30 |
|
To book peforated aluminum sheet, need below parameters:
Overall dimension × hole diameter × hole spacing × edge reserved × hole arrangement
